Force H3X Hybrid

The latest Force H3X Series is the Next Level Residential Energy Solution. It's highly integrated with battery, BMS, inverter and EMS into one system and it support single/three phase(s) and hybrid/AC-coupled scenarios.

Request a Quote

Advantages

On-Demand Versatility

Single Phase/Three Phase.
Suitable for both residential and small-scale C&I.

One-Stop Solution & Effortless Installation

BMS+Inverter+EMS Highly integrated. 15min installation &commissioning. Automatic paralleling,easy set-up

Trustworthy Safety Design

Vertical integrated manufacturing. Reliable product safety design. AI-driven smart protection. Various safety certifications, unit level UL9540A.

Extraordinary Performance

100% three phase load unbalance Supported.

Intelligent Solutions

Dynamic control:Optimized energy usage strategy. Fault diagnosis system. Remote control of pv and heat pump.

Technical Specifications

Force H3X Hybrid

Battery Module

FH10050

Number of Battery Modules

1/2/3/4

Maximum PV Power (kW)

9.6

System Rated Capacity (kWh)

5.12/10.24/15.36/20.48

Nominal Power (kW)

3.6/5/6/8

IP Rate

IP55

Maximum Power (kW)

9.6/12.8

Maximum Dc Input Voltage (Vdc)

600

Start Up Voltage (Vdc)

Number of MPPT

2/3

Number of PV Strings Per MPPT

MPPT Voltage Range (Vdc)

80~550

MPPT Full Load Voltage Range (Vdc)

190~520

Maximum Current (A)

Short Circuit Current Per MPPT(A)

Surge Protection

Type II

Nominal AC Voltage/Frequency (Vac)

230@50/60Hz

Grid Voltage Range (Vac)

172.5~264.5

Grid Connection

L/N/PE

Nominal AC Power (kW)

3.6/5/6/8

Maximum Grid Input Power (kW)

5.7/7.5/9.6/12

Rated Output Voltage (Vac)

230±1%

ON/Off-Grid Switching Time (ms)

≤10

Rated Of-Grid Power (kVA)

3.6/5/6/8

Peak Of-Grid Power (60s)/Estimate (kVA)

4.32/6/7.2/9.6

Maximum Parallel

Maximum Efficiency

(400V PV) 97%

European Efficiency

97%

Short Circuit Current Per MPPT(A)

European Efficiency

97%

Maximum Efficiency

(600V PV) 97%

Maximum Parallel

Peak Of-Grid Power (60s)/Estimate (kVA)

9.6/12/14.4/18

Rated Of-Grid Power (kVA)

8/10/12/15

ON/Off-Grid Switching Time (ms)

≤10

Rated Output Voltage (Vac)

400

Maximum Grid Input Power (kW)

12/15/18/22.5

Nominal Power (kW)

8/10/12/15

Grid Connection

3W/N/PE

Grid Voltage Range (Vac)

320~480

Nominal AC Voltage/Frequency (Vac)

400@50/60Hz

Surge Protection

Type II

Main System

FH10050

Number of Battery Modules

1/2/3/4

Maximum Dc Input Voltage (Vdc)

600

Maximum Current (A)

MPPT Full Load Voltage Range (Vdc)

280~850

MPPT Voltage Range (Vdc)

200~850

Number of PV Strings Per MPPT

Number of MPPT

Start Up Voltage (Vdc)

200

Maximum DC Input Voltage (Vdc)

1000

Maximum Power (kW)

Start Up Voltage (Vdc)

200

IP Rate

IP55

Nominal AC Power (kW)

8/10/12/15

System Rated Capacity (kWh)

10.24/15.36/20.48/25.6/30.72/35.84

Maximum PV Power (kW)

Number of Battery Modules

2/3/4/5/6/7

System Battery Voltage (Vdc)

100~500/120~850

Maximum Charge and Discharge Current (A)

40/50

System Dimensions (Width*Depth*Height, mm)

540*350*(565/735/905/1075) /540*350*(780/950/1120/1290/1460/1630)

System Weight (kg)

69/108/147/186/118/157/196/235/274/313

System Installation Method

Floor Installation (Wall-Mounted Optional for 5/10/15 Series)

System Operating Temperature Range (℃)

-10~55

System Operating Temperature Range (℃)

0~95%

System Salt Spray Level

C5M

System Working Altitude (m)

≤3000

Common Noise Level (@ 1 meter *In Nominal Condition, dB)

<29

Cooling

Air Cooling

Communication Portal EPO

WIFI/WLAN/Bluetooth

EPO

Installed

AFCI

2.0@IEC 63027

Standard Compliance

UN38.3/IEC61000-6/VDE-AR-E-2510-50 2017-05/IEC62619: 2022/IEC60730-1/1S013849/IEC62477-1: 2022/EN 62477-1: 2012+A12: 2021/IEC62109-1: 2010/IEC62109-2: 2011/VDE-AR-N-4105: 2018/DIN VDE V 0124-100: 2020/EN50549-10/EN50549-1/PPDS Annex: 2022+EN50549-10/C10/11+EN50549-10/EIFS+EN50549-10/ CEI0-21/RD1699 RD661 RD413/UNE 217002:2020/NTS Version 2.1: 2021/UNE 217001: 2021/AS 4m.2/AS60947.3/G98/G99/TOR/ PTPiREE/NA-EEA-NE7-CH 2020

Battery Module

FH10050

Battery Module Capacity (kWh)

5.12

Depth of Discharge

95%

Charge/Discharge Standard(A)

Charge/Discharge Normal(A)

Charge/Discharge MAX(A)

55@15min

Cycle Life (@25°C)

＞8000
